PRODUCTS
Copper Rod
Oxygen Free –
UPCAST Rod
| Attributes | Specified values for UPCAST Copper |
|---|---|
| Copper content | 99.99 % Minimum |
| Oxygen content | 10 ppm Maximum |
| Copper grade | C10100 / OFE, C10200 / OF or equivalent |
| Condition | Cast |
| Copper Rod Size | 12.5 – 20 mm +0.20/-0.60 mm |
| Electrical conductivity (IACS @ 20° C) |
100 % Minimum |
| Tensile strength | – |
| Elongation at fracture (250 mm gauge length) |
– |
| Surface condition | Clean and free from scratches |
| Packaging in coils: | |
| Internal diameter | 800 ± 100 mm |
| Outer diameter | 1500 ± 100 mm Sea worthy packing on wooden pallet |
| Coil weight | Up to 4.0 MT |
| Other requirements | On mutual agreement |
